Door weight: Up to 600 lbs with the standard two-hanger setup on color-matched steel wheels. If you add the Delrin wheel upgrade, capacity drops to 300 lbs per door — check your door weight against that before selecting it. Over 600 lbs, email us before ordering; a third hanger adds two more rollers and raises the rating, but we'll want to confirm your wall structure at that weight rather than quote a number blind.
Door thickness: 1-3/8 in to 2-1/4 in. Outside this range, email us before ordering.
Door width and hanger count: Two hangers handle doors up to 48 in wide. Between 48 and 60 in, a third hanger is optional. Above 60 in it's required. A third hanger isn't a checkout option — request one on our custom quote page with your door width and we'll spec it. On the horseshoe a third hanger means two more rollers, not one.
Wall clearance beside opening: Must equal full door width on the slide side. Limited clearance? See bypass or bifold hardware.
Ceiling clearance above the door: 5-1/2 in minimum, measured above the top of the door — not above the rough opening. A taller door raises the track, so measure against your final door height. The standard duty horseshoe fits in 4 in if you're tight — but only if your door is also within its 250 lb rating and 1-3/4 in thickness limit.
Wall backing: At 600 lbs, solid backing is not optional: a 1×6 hardwood header board or solid wood blocking in the wall. For a header board, use solid hardwood, minimum 1×6 — oak, maple, or poplar, not pine — spanning the full track length and lag-bolted into every stud with 3/8 in × 3 in lag bolts. Blocking goes between the studs before the wall is closed and runs the full length of the track. The entire weight of the door transfers through the track mounting points, and drywall or intermittent blocking will fail over time. Either one also decouples the track's bolt spacing from your stud spacing, so you're never limited to where the track holes happen to line up with studs. If you're at all uncertain about your wall structure for a door this heavy, email us before installing.
Door width: Your door must be wider than the rough opening. For standard rooms plan for 2 in of wall overlap on each side — opening + 4 in. For bedrooms and bathrooms, 3 in per side gives better privacy — opening + 6 in. If wall space is tight, 1/2 in per side is the minimum functional overlap, but treat that as a floor rather than a target. See our measuring guide for full sizing formulas.
Door height: Measure the rough opening height and add 1 in minimum — the extra inch covers the top of the opening, and the hardware sets a 3/8 in gap at the floor. If there is casing or trim above the opening, the door needs to be at least as tall as the top of that casing so the track clears it entirely. Never mount the track to trim. Going taller raises the track, so recheck your ceiling clearance before ordering. With thick carpet, confirm the floor clearance holds along the full travel path.
Trim beside the opening: The kit includes spacers that set the track's baseline standoff for a flat wall, but clearing projecting casing or baseboard takes extra spacers — that's the trim clearance kit you select above. Measure how far your trim stands off the wall and match it: 1/2 in, 7/8 in, or 1-1/4 in. Projecting more than 1-1/4 in? Contact us before ordering — that's beyond every tier.
This track carries a lag bolt at the end, so the last mounting point sits where the door actually parks rather than wherever the stud spacing ran out. It is the difference you are paying for, and it shows up most on biparting pairs and long runs: what the end bolt is for.
